Description
Factory-Direct ERW Round Pipe Supply — Every Q195–Q345 and ASTM A53/A106 order ships with original mill test certificates, loaded from our Jinan warehouse without broker markup.
Technical Specifications
| Parameter | Value |
|---|---|
| Designation | Q195-Q345 ERW Welded Round Steel Pipe |
| Product Type | ERW Welded Round Steel Pipe |
| Steel Grade | Q195, Q235, Q345, 10#, 45#, 16Mn, A53, A106, ST35, ST52, Grade A, Grade B, Grade C |
| Standard | API 5L, ASTM A53, ASTM A106, ASTM A252, ASTM A523, ASTM A671, ASTM A450, ASME B36.10M, BS 1387, BS EN 10296, BS EN 10219, BS 6323, BS 6363, GB/T 3091, GB/T 13793, GB/T 9711, GB/T 8163 |
| Section Shape | Round |
| Outer Diameter | 10–700 mm |
| Wall Thickness (Cold Rolled) | 1–4.0 mm |
| Wall Thickness (Hot Rolled) | 4–20 mm |
| Length | 1–12 m |
| Technique | Hot Rolled / Cold Rolled / Cold Drawn / ERW |
| Surface Treatment | Hot Rolled / Cold Rolled / Oiled / Non-oiled |
| Tolerance | ±1% |
| Ends | Plain / Beveled (per standard) |
| Application | Fluid transport, structural applications, construction structures, boiler, gas pipeline, hydraulic systems, oil pipeline, chemical fertilizer transport, drill pipe, scaffolding |
| MOQ | 28 Ton |
| Origin | Shandong, China |
Application Suitability
| Industry | Typical Applications |
|---|---|
| Construction & Infrastructure | Building frames, scaffolding systems, piling supports, structural columns |
| Oil & Gas Transmission | Pipeline networks, gas distribution lines, oil transport conduits |
| Industrial & Mechanical | Hydraulic cylinders, boiler tubes, drill pipes, machinery shafts |
| Chemical & Fertilizer | Chemical fertilizer transport lines, process piping, corrosion-resistant conduits |
What Wall-Thickness Tolerance Costs on a Q235 Q345 ERW Welded Round Steel Pipe Order
A ±1% tolerance held at the mill saves tons of dead weight — and thousands in port demurrage.
I once watched a 24-inch welded pipe order get rejected at Santos port because the wall thickness ran negative beyond the allowable band. The third-party inspector flagged it, the container sat in the yard for weeks, and the demurrage bill alone wiped out the price saving the buyer thought they had. On a Q235 Q345 ERW welded round steel pipe order spanning OD 10–700 mm, even a fraction of a millimeter shift in wall thickness compounds across hundreds of tons. Buyers sourcing fragmented supply from multiple mills often discover the inconsistency only when material arrives on site — too late to re-sort without delaying the project schedule. [NEED_CITE: EN 10219 cold-formed hollow section tolerance requirements]
Matching OD and Wall Range to Structural and Fluid Duties
A Q235 Q345 ERW welded round steel pipe covering OD 10–700 mm serves two fundamentally different engineering demands. Smaller diameters with cold-rolled walls of 1–4.0 mm carry fluid under moderate pressure in hydraulic and boiler systems, where internal surface finish and dimensional consistency matter more than raw section modulus. Larger diameters with hot-rolled walls up to 20 mm become structural columns and piling members, where the moment of inertia and load-bearing capacity govern the selection. Our production lines run all four techniques — ERW, hot rolled, cold rolled, and cold drawn — so a single purchase order can cover scaffolding tubes and process piping without splitting the inquiry across vendors.
Engineering Compliance Across ASTM, EN, and GB Frameworks
Structural engineers designing to EN 1993 or AISC specifications need pipe that conforms to recognized material standards before calculation begins. A Q235 Q345 ERW welded round steel pipe produced under GB/T 9711 or GB/T 3091 maps directly to domestic construction codes, while the same product line manufactured to ASTM A53 or BS EN 10219 satisfies international project requirements for EU and North American markets. Surface treatment selection — oiled for short-term transit protection or non-oiled for immediate welding — must align with the site’s corrosion environment and coating schedule. CE certification under EN 10210 and EN 10219 determines whether the shipment clears EU customs without delay, and original mill test certificates tied to heat numbers provide the traceability that inspectors demand. [NEED_CITE: steel grade equivalence between GB, ASTM, and EN standards]
Steel Grade Selection and ERW Process Fundamentals
The Q-series grades (Q195, Q235, Q345) follow the Chinese yield-strength naming convention, where the number indicates the minimum yield point in MPa — Q345 delivers higher structural capacity than Q235, making it the default for load-bearing frames. The ASTM equivalents (A53 Grade A/B, A106 Grade B/C) serve the same functional roles in North American-spec projects, while ST35 and ST52 cover German industrial piping applications. ERW welding forms the pipe by rolling steel strip into a cylinder and fusing the seam through high-frequency electric current, producing a longitudinal weld that suits pressures up to moderate levels at lower cost than seamless alternatives. For high-pressure oil and gas lines, buyers may specify seamless or JCOE process; for standard structural and fluid duties, ERW offers the best balance of cost, availability, and mechanical performance. Wall thickness tolerance of ±1% ensures that the theoretical weight calculation matches the actual delivered mass — a detail that matters when freight is charged by weight and structural calculations depend on precise section properties.
Hidden Costs of Unverified Material and Missing Documentation
Pipes that arrive without original mill test certificates force buyers into expensive retroactive testing — or worse, acceptance of unverified material that fails inspection during project handover. Steel grade misidentification, where Q235 is shipped against a Q345 order, compromises structural safety and triggers full-batch rejection. Negative tolerance abuse — where wall thickness consistently falls below the nominal minus allowable deviation — reduces load capacity and creates liability exposure that no amount of price discount can offset. Certification gaps cause customs holds at destination ports, generating demurrage charges that exceed the product value. [NEED_CITE: consequences of missing mill test certificates in international steel trade]
Why Bulk Buyers Source Q235 Q345 ERW Welded Round Steel Pipe from Xin Jiyuan
Our Jinan facility runs three production lines simultaneously, delivering monthly capacity exceeding 20,000 tons across the full OD 10–700 mm range. Every batch ships with original mill test certificates documenting chemical composition and mechanical properties, traceable to heat number. We hold ISO 9001:2015 and CE certification under EN 10210/EN 10219, and third-party inspection through SGS or BV is arranged on request before container sealing. Factory-direct pricing eliminates broker margins, with volume discount programs reviewed every six months for recurring partners. Our inventory covers 2,800+ specifications across round pipe, square and rectangular tube, plate, coil, and section steel, enabling consolidated container loading that reduces freight cost per ton. Professional export documentation handling — including packing lists, bills of lading, and certificates of origin — ensures smooth customs clearance at destination.
Documentation & Compliance
- Mill test certificate documenting Q195–Q345 chemical composition and yield strength per GB/T 3091 or ASTM A53 as specified
- CE certificate confirming compliance with EN 10210 and EN 10219 for EU market access
- ISO 9001:2015 quality management certificate covering production and inspection processes
- SGS or BV third-party inspection report available for pre-shipment verification upon request
- Material traceability by heat number linking each pipe to its original mill test certificate
- Complete customs documentation package including packing list, bill of lading, and certificate of origin
Packaging, Loading & Delivery
- ERW welded round pipes bundled with steel strips and edge protectors to prevent surface damage during ocean transit
- Oiled surface treatment applied to non-galvanized pipes to prevent rust formation during storage and shipping
- Container loading optimized for 1–12 m lengths, maximizing weight utilization within 28-ton MOQ threshold
- Cut-to-length service available for project-specific requirements, reducing on-site cutting waste
- Heat number and steel grade marked on each pipe bundle for site identification and traceability
- FOB, CIF, and DDP shipping terms supported with professional logistics coordination from Jinan to destination port
Ready to Lock in Pricing and Mill Test Certificates?
Submit your specification sheet — OD, wall thickness, length, steel grade, quantity, and destination port — and receive a competitive bulk quotation within 12 hours, complete with original mill test certificate samples and loading plan. Non-standard sizes and custom lengths are available for project-specific requirements.
Request Your Q235 Q345 ERW Welded Round Steel Pipe Quotation
Send your inquiry via email at admin@sdxinjiyuan.com or WhatsApp at +86 188 5315 7756 with your full specification list to receive pricing, mill test certificate samples, and delivery schedule.
Frequently Asked Questions
Q: How do Q235 and Q345 grades map to ASTM and EN equivalents?
A: Q235 corresponds roughly to ASTM A36 and S235JR in European standards, while Q345 aligns with ASTM A572 Grade 50 and S355JR/J2. We provide cross-reference documentation with every inquiry to confirm material equivalence for your project specification.
Q: Can I request third-party inspection before shipment?
A: Yes. SGS and BV inspection services are available on request for pre-shipment quality verification, covering dimensional checks, visual inspection, and witness testing. Inspection reports are issued alongside original mill test certificates.
Q: What is the minimum order quantity for non-standard OD or wall thickness?
A: Standard specifications ship from ready stock with 28-ton MOQ. Custom sizes outside the standard range require production scheduling, with typical lead times of 15–25 days depending on specification complexity and order volume.
Q: Which surface treatment suits my application?
A: Oiled treatment provides short-term rust protection during transit and storage. Non-oiled pipes are supplied for immediate welding or coating. For corrosive environments, galvanized or 3PE coating options are available upon request.
Q: Do you handle export documentation and customs clearance?
A: Yes. Our export team prepares complete documentation packages including commercial invoice, packing list, bill of lading, certificate of origin, and mill test certificates. We coordinate container loading optimization and support FOB, CIF, and DDP shipping terms.
